11.2.4 GROUP:TERMINAL SELECTION PARAMETERS
GROUP:TERMINAL SELECTION PARAMETERSGROUP:TERMINAL SELECTION PARAMETERS
GROUP:TERMINAL SELECTION PARAMETERS
Register Function / Title Bank Mask Adjustment Range Multiplier
44
INPUT TERMINAL
SELECTION
0 / 1 0001 0000: Standard functions (0)
0001: Individual selections (1)

45 1
“R” INPUT TERMINAL
FUNCTION
0 / 1 FFFF
0000 ∼ FFFF (0 ∼ 54) 
46
“S1” INPUT
TERMINAL FUNCTION
Refer to Table 7 (page 37)
47
“S2” INPUT
TERMINAL FUNCTION
48
“S3” INPUT
TERMINAL FUNCTION
49
“S4” INPUT
TERMINAL FUNCTION
4A
“F” INPUT TERMINAL
FUNCTION
4B
“RES” INPUT
TERMINAL FUNCTION
4C
“ST” INPUT
TERMINAL FUNCTION
4D
“S5” INPUT
TERMINAL FUNCTION
4E
“S6” INPUT
TERMINAL FUNCTION
4F
“S7” INPUT
TERMINAL FUNCTION
50
POTENTIAL TERMINAL
FUNCTION
51
R,S1-S7 TERMINAL
RESPONSE TIME
0 / 1 00FF
0001 ∼ 0064 (1 ∼ 100)
1
52
F INPUT TERMINAL
RESPONSE TIME
0 / 1 00FF
0001 ∼ 0064 (1 ∼ 100)
1
53
RES INPUT TERMINAL
RESPONSE TIME
0 / 1 00FF
0001 ∼ 0064 (1 ∼ 100)
1
54
ST INPUT TERMINAL
RESPONSE TIME
0 / 1 00FF
0001 ∼ 0064 (1 ∼ 100)
1
55
“RCH” CONTACTS
FUNCTION
0 / 1 FFFF
0 ∼ FFFF (0 ∼ 63)
Refer to Table 8 (page 38)

56
“RCH” CONTACTS DELAY
TIME
0 / 1 00FF
0001 ∼ 0064 (1 ∼ 100)
1
57
“RCH” CONTACTS HOLD
TIME
0 / 1 00FF
0001 ∼ 0064 (1 ∼ 100)
1
58
“LOW” CONTACTS
FUNCTION
0 / 1 FFFF
0 ∼ FFFF (0 ∼ 63)
Refer to Table 8 (page 38)

59
“LOW” CONTACTS DELAY
TIME
0 / 1 00FF
0001 ∼ 0064 (1 ∼ 100)
1
5A
“LOW” CONTACTS HOLD
TIME
0 / 1 00FF
0001 ∼ 0064 (1 ∼ 100)
1
5B
“FL” CONTACTS
FUNCTION
0 / 1 FFFF
0 ∼ FFFF (0 ∼ 63)
Refer to Table 8 (page 38)

5C
“FL” CONTACTS DELAY
TIME
0 / 1 00FF
0001 ∼ 0064 (1 ∼ 100)
1
5D
“FL” CONTACTS HOLD
TIME
0 / 1 00FF
0001 ∼ 0064 (1 ∼ 100)
1
5E
“OUT” CONTACTS
FUNCTION
0 / 1 FFFF
0 ∼ FFFF (0 ∼ 63)
Refer to Table 8 (page 38)

5F
“OUT” CONTACTS DELAY
TIME
0 / 1 00FF
0001 ∼ 0064 (1 ∼ 100)
1
