11.2.6 GROUP:FREQUENCY SETTING PARAMETERS
GROUP:FREQUENCY SETTING PARAMETERSGROUP:FREQUENCY SETTING PARAMETERS
GROUP:FREQUENCY SETTING PARAMETERS
Register Function / Title Bank Mask Adjustment Range Multiplier
81
FREQUENCY PRIORITY
SELECTION #1
0 / 1 0007 0001: RR (1)
0002: IV (2)
0003: RX (3)
0004: PG (4)
0005: BIN (5)

82
FREQUENCY PRIORITY
SELECTION #2
0 / 1 0038 0008: RR (1)
0010: IV (2)
0018: RX (3)
0020: PG (4)
0028: BIN (5)

83
ANALOG INPUT FILTER
0 / 1 0003 0000: No filter (0)
0001: Small filter (1)
0002: Medium filter (2)
0003: Large filter (3)

84
RR TERMINAL STANDARD
OR ADJUSTABLE
0 / 1 0002 0000: Standard (0)
0002: Adjustable (1)

85 1
RR REFERENCE
SETTING POINT #1
0 / 1 00FF
0000 ∼ 0064 (0 ∼ 100)
1
86
RR REF POINT #1
FREQUENCY
0 / 1 FFFF
0000 ∼ Fmax
0.01
87
RR REFERENCE
SETTING POINT #2
0 / 1 00FF
0000 ∼ 0064 (0 ∼ 100)
1
88
RR REF POINT #2
FREQUENCY
0 / 1 FFFF
0000 ∼ Fmax
0.01
89
IV TERMINAL STANDARD
OR ADJUSTABLE
0 / 1 0004 0000: Standard (0)
0004: Adjustable (1)

8A 1
IV REFERENCE
SETTING POINT #1
0 / 1 00FF
0000 ∼ 0064 (0 ∼ 100)
1
8B
IV REF POINT #1
FREQUENCY
0 / 1 FFFF
0000 ∼ Fmax
0.01
8C
IV REFERENCE
SETTING POINT #2
0 / 1 00FF
0000 ∼ 0064 (0 ∼ 100)
1
8D
IV REF POINT #2
FREQUENCY
0 / 1 FFFF
0000 ∼ Fmax
0.01
8E
RX TERMINAL STANDARD
OR ADJUSTABLE
0 / 1 0008 0000: Standard (0)
0008: Adjustable (1)

8F 1
RX REFERENCE
SETTING POINT #1
0 / 1 00FF
009C ∼ 00FF, 0000 ∼ 0064
(-100 ∼ -1, 0 ∼ 100)
1
90
RX REF POINT #1
FREQUENCY
0 / 1 FFFF
-Fmax ∼ Fmax
0.02
91
RX REFERENCE
SETTING POINT #2
0 / 1 00FF
009C ∼ 00FF, 0000 ∼ 0064
(-100 ∼ -1, 0 ∼ 100)
1
92
RX REF POINT #2
FREQUENCY
0 / 1 FFFF
-Fmax ∼ Fmax
0.02
93
PG TERMINAL STANDARD
OR ADJUSTABLE
0 / 1 0010 0000: Standard (0)
0010: Adjustable (1)

94 1
PG REFERENCE
SETTING POINT #1
0 / 1 00FF
009C ∼ 00FF, 0000 ∼ 0064
(-100 ∼ -1, 0 ∼ 100)
1
95
PG REF POINT #1
FREQUENCY
0 / 1 FFFF
-Fmax ∼ Fmax
0.02
96
PG REFERENCE
SETTING POINT #2
0 / 1 00FF
009C ∼ 00FF, 0000 ∼ 0064
(-100 ∼ -1, 0 ∼ 100)
1
97
PG REF POINT #2
FREQUENCY
0 / 1 FFFF
-Fmax ∼ Fmax
0.02
