11.2.10 GROUP:COMMUNICATION SETTING PARAMETERS
GROUP:COMMUNICATION SETTING PARAMETERSGROUP:COMMUNICATION SETTING PARAMETERS
GROUP:COMMUNICATION SETTING PARAMETERS
Register Function / Title Bank Mask Adjustment Range Multiplier
1D0 ∼
200
Reserved
   
201
RS232 BAUD RATE
1 0018 0000: 2400 baud (0)
0008: 4800 baud (1)
0010: 9600 baud (2)

202
NUMBER OF DATA BITS
1 0040 0000: 7 bits (0)
0040: 8 bits (1)

.203
PARITY SETTING
1 0080 0000: Even parity (0)
0080: Odd parity (1)

204
INVERTER ID NUMBER
1 00FF
0000 ∼ 00FF (0 ∼ 255) Note 1
1
205
COMMUNICATION
SELECTION
1 0007 0000: OFF (0)
0001: RS485 (1)
0002: Profibus, Modbus, DNet (2)
0003: TOSLINE S-20 (3)
0004: 12 bit binary input (4)
0005: 3-digit BCD (0.1Hz) (5)
0006: 3-digit BCD (1Hz) (6)

206 1
MASTER/SLAVE
SELECTION
1 0018 0000: Slave (0)
0008: Master (frequency command)
(1)
0010: Master (output frequency) (2)

207
RS485 BAUD RATE
1 0004 0000: Normal mode (0)
0004: High-speed mode (1)

208 2
TOSLINE-F10
COMMAND INPUT
1 0003 0000: OFF (0)
0001: Frequency command (1)
0002: Command input (2)
0003: Both (1) and (2) (3)

209
TOSLINE-F10
MONITOR OUTPUT
1 003C 0000: (0) 0020: (8)
0004: (1) 0024: (9)
0008: (2) 0028: (10)
000C: (3) 002C: (11)
0010: (4) 0030: (12)
0014: (5) 0034: (13)
0018: (6) 0038: (14)
001C: (7) 003C: (15 )

20A
TOSLINE-F10 COMM
ERROR MODE
1 0080 0000: Data cleared (0)
0080: Data retained (1)

20B 3
TOSLINE-S20
RECEIVE ADDRESS
1 FFFF
0000 ∼ 03FF (0 ∼ 1023)
1
20C
TOSLINE-S20
TRANSMIT ADDRESS
1 FFFF
0000 ∼ 03FF (0 ∼ 1023)
1
20D
TOSLINE-S20
COMMAND INPUT
1 001F
0000 ∼ 001F (0 ∼ 31)
1
20E
TOSLINE-S20
MONITOR OUTPUT
1 001F
0000 ∼ 001F (0 ∼ 31)
1
20F
TOSLINE-S20 FREQ
REF ADDR SELECT
1 0001 0000: Disable (0)
0001: Enable (1)
1
210 1
TOSLINE-S20
FREQ REFERENCE
ADDR
1 FFFF
0000 ∼ 03FF (0 ∼ 1023)
1
Note 1: Although the INVERTER ID NUMBER parameter can be set from 0 to 255, the allowable Profibus slave
addresses range only from 0 to 125. Therefore, if this parameter is set to a value from 126 to 255, the
Profibus interface card will trip “OPTION PCB ERROR” upon initialization.
