Toshiba G3 TOSVERT-130 User Manual

39
11.2.5
11.2.511.2.5
11.2.5 GROUP:SPECIAL CONTROL PARAMETERS
GROUP:SPECIAL CONTROL PARAMETERS GROUP:SPECIAL CONTROL PARAMETERS
GROUP:SPECIAL CONTROL PARAMETERS
Register Function / Title Bank Mask Adjustment Range Multiplier
69
START-UP FREQUENCY
0 / 1 FFFF
0000 ∼ 03E8 (0.00 ∼ 10.00)
0.01
6A ∼ 6F
Reserved
   
70
END FREQUENCY
0 / 1 FFFF
0000 ∼ 0BB8 (0.00 ∼ 30.00)
0.01
71
RUN FREQUENCY
0 / 1 FFFF
0000 ∼ Fmax
0.01
72
RUN FREQUENCY
HYSTERESIS
0 / 1 FFFF
0000 ∼ 0BB8 (0.00 ∼ 30.00)
0.01
73
ENABLE JUMP
FREQUENCIES
0 / 1 0080 0000: Function OFF (0)
0080: Function ON (1)

74 1
JUMP FREQUENCY #1
0 / 1 FFFF
0000 ∼ Fmax
0.01
75
JUMP FREQUENCY #1
BANDWIDTH
0 / 1 FFFF
0000 ∼ 0BB8 (0.00 ∼ 30.00)
0.01
76
JUMP FREQUENCY #2
0 / 1 FFFF
0000 ∼ Fmax
0.01
77
JUMP FREQUENCY #2
BANDWIDTH
0 / 1 FFFF
0000 ∼ 0BB8 (0.00 ∼ 30.00)
0.01
78
JUMP FREQUENCY #3
0 / 1 FFFF
0000 ∼ Fmax
0.01
79
JUMP FREQUENCY #3
BANDWIDTH
0 / 1 FFFF
0000 ∼ 0BB8 (0.00 ∼ 30.00)
0.01
7A ∼ 7F
Reserved
   
80
PWM CARRIER FREQUENCY
(Note 1)
0 / 1 00FF
0005 ∼ 0064 (0.5 ∼ 10.0)
0.1
Note 1: Actual adjustment range depends on inverter rating.
