Toshiba G3 TOSVERT-130 - Group:am;Fm Terminal Adjustment Params

50
Register Function / Title Bank Mask Adjustment Range Multiplier
211
TOSLINE-S20 COMM
ERROR MODE
1 0002 0000: Data cleared (0)
0002: Data retained (1)
1
212
TOSLINE-S20 COMM
OPTION RESET
1 0004 0000: No effect (0)
0004: Reset (1)
1
213
RS485/12-BIT BINARY
BIAS,GAIN
0 / 1 0020 0000: OFF (0)
0020: ON (1)

214 1
RS485/12-BIT
BINARY POINT #1
0 / 1 00FF
0000 ∼ 0064 (0 ∼ 100)
1
215
RS485/12-BIT
BINARY PT. #1
FREQ
0 / 1 FFFF
0000 ∼ Fmax (0 ∼ Fmax)
0.01
216
RS485/12-BIT
BINARY POINT #2
0 / 1 00FF
0000 ∼ 0064 (0 ∼ 100)
1
217
RS485/12-BIT
BINARY PT. #2
FREQ
0 / 1 FFFF
0000 ∼ Fmax (0 ∼ Fmax)
0.01
11.2.11
11.2.1111.2.11
11.2.11 GROUP:AM/FM TERMINAL ADJUSTMENT PARAMS
GROUP:AM/FM TERMINAL ADJUSTMENT PARAMSGROUP:AM/FM TERMINAL ADJUSTMENT PARAMS
GROUP:AM/FM TERMINAL ADJUSTMENT PARAMS
Register Function / Title Bank Mask Adjustment Range Multiplier
218
FM TERMINAL FUNCTION
SELECTION
0 / 1 FFFF 1194: Pre-comp ref. frequency (0)
6686: Post-comp output freq. (1)
1500: Frequency setting (2)
2576: Output current (3)
2689: DC voltage (4)
5668: Output voltage (5)
3684: Torque current (6)
2688: Excitation current (7)
7506: PID feedback value (8)
0584: Motor overload ratio (9)
0586: Inverter overload ratio (10)
0588: DBR overload ratio (11)
835C: Input power (12)
835E: Output power (13)
A000: Fixed output (14)
2304: Peak output current (15)
8302: Peak input voltage (16)

219
FREQUENCY METER
ADJUSTMENT
0 / 1 FFFF
0000 ∼ FFFF
1
21A
AM TERMINAL FUNCTION
SELECTION
0 / 1 FFFF Same as FM TERMINAL FUNCTION
SELECTION

21B
CURRENT METER
ADJUSTMENT
0 / 1 FFFF
0000 ∼ FFFF
1
