Toshiba G3 TOSVERT-130 - Group:utility Parameters

51
11.2.12
11.2.1211.2.12
11.2.12 GROUP:UTILI
GROUP:UTILIGROUP:UTILI
GROUP:UTILITY PARAMETERS
TY PARAMETERSTY PARAMETERS
TY PARAMETERS
Register Function / Title Bank Mask Adjustment Range Multiplier
21C
INDUSTRIAL
APPLICATIONS
(previous setting monitor for
read use only)
0 / 1 00FF 0000: Std. Shpmt. setting (0)
0001: Pump application (1)
0002: Fan application (2)
0003: Conveyor application (3)
0004: Hoist application (4)
0005: Textiles application (5)
0006: Machine tools appl. (6)

21D
INDUSTRIAL
APPLICATIONS
(for write use) (∗
∗∗
∗)
0 / 1 00FF 0000: Does nothing (0)
0011: Pump application (1)
0012: Fan application (2)
0013: Conveyor application (3)
0014: Hoist application (4)
0015: Textiles application (5)
0016: Machine tools appl. (6)

21E
STANDARD SETTING MODE
SELECTION (∗
∗∗
∗)
0 / 1 00FF 0000: Does nothing (0)
0001: 50Hz std. Settings (1)
0002: 60Hz std. Settings (2)
0003: Factory settings (3)
0004: Trip clear (4)
0005: Save user-set param. (5)
0006: TYPE 5 reset (6)
0007: Initialize typeform (7)

21F
COMMAND MODE
SELECTION
0 / 1 0007 0000: Only RS232C valid (0)
0001: Terminal input valid (1)
0002: Panel input valid (2)
0003: Communication interface input
valid (3)
0004: local/remote valid (4)

220
FREQUENCY MODE
SELECTION
0 / 1 0038 0000: Only RS232C valid (0)
0008: Terminal input valid (1)
0010: Panel input valid (2)
0018: Communication/12-bit binary
interface input valid (3)
0020: local/remote valid (4)

221
PANEL OPERATION MODE
SELECTION
0 / 1 00FB
0000 ∼ 003F (0 ∼ 63)
(except 0004, 0008, 000C....)
1
222
PASS NUMBER
0 / 1 00FF
0000 ∼ 0063 (0 ∼ 99)
1
223
CPU VERSION
2 FFFF (Monitor only)

224
ROM VERSION
3 or 6 FFFF (Monitor only)

225
EEPROM VERSION
1 FFFF (Monitor only)

226
INVERTER TYPEFORM
0 00FF Refer to Table 9 (page 54)

227
STATUS MONITOR #1
DISPLAY SELECT
0 / 1 FFFF
0001 ∼ 0010 (1 ∼ 16)
1
228
STATUS MONITOR #2
DISPLAY SELECT
0 / 1 FFFF
0001 ∼ 0010 (1 ∼ 16)
1
229
STATUS MONITOR #3
DISPLAY SELECT
0 / 1 FFFF
0001 ∼ 0010 (1 ∼ 16)
1
22A
STATUS MONITOR #4
DISPLAY SELECT
0 / 1 FFFF
0001 ∼ 0010 (1 ∼ 16)
1
22B
FREQUENCY UNITS SCALE
FACTOR
0 / 1 FFFF
0000 ∼ 4E20 (0.00 ∼ 200.00)
0.01
22C
FREQUENCY DISPLAY
RESOLUTION
0 / 1 0003 0000: 1Hz (0)
0001: 0.1Hz (1)
0002: 0.01Hz (2)

