11.2.8 GROUP:PATTERN RUN CONTROL PARAMETERS
GROUP:PATTERN RUN CONTROL PARAMETERSGROUP:PATTERN RUN CONTROL PARAMETERS
GROUP:PATTERN RUN CONTROL PARAMETERS
Register Function / Title Bank Mask Adjustment Range Multiplier
146
PATTERN RUN SELECTION
0 / 1 0008 0000: OFF (0)
0008: ON (1)

147 1
PATTERN RUN
CONTINUE MODE
0 / 1 0001 0000: reset on stop (0)
0001: switch when done (1)

148
PATTERN GROUP #1
SPEED #0
1 00FF 0000: Skip (0) 1
149
PATTERN GROUP #1
SPEED #1
0001 ∼ 000F: Speeds 1 ∼ 15
150
PATTERN GROUP #1
SPEED #2
151
PATTERN GROUP #1
SPEED #3
152
PATTERN GROUP #1
SPEED #4
153
PATTERN GROUP #1
SPEED #5
154
PATTERN GROUP #1
SPEED #6
155
PATTERN GROUP #1
SPEED #7
156
PATTERN GROUP #1
NUMBER OF CYCLES
0 / 1 00FF
0001 ∼ 00FF: 1 ∼ 255
1
157
PATTERN GROUP #2
SPEED #0
1 00FF 0000: Skip (0) 1
158
PATTERN GROUP #2
SPEED #1
0001 ∼ 000F: Speeds 1 ∼ 15
159
PATTERN GROUP #2
SPEED #2
15A
PATTERN GROUP #2
SPEED #3
15B
PATTERN GROUP #2
SPEED #4
15C
PATTERN GROUP #2
SPEED #5
15D
PATTERN GROUP #2
SPEED #6
15E
PATTERN GROUP #2
SPEED #7
15F
PATTERN GROUP #2
NUMBER OF CYCLES
0 / 1 00FF
0001 ∼ 00FF: 1 ∼ 255
1
160
PATTERN GROUP #3
SPEED #0
1 00FF 0000: Skip (0) 1
161
PATTERN GROUP #3
SPEED #1
0001 ∼ 000F: Speeds 1 ∼ 15
162
PATTERN GROUP #3
SPEED #2
163
PATTERN GROUP #3
SPEED #3
164
PATTERN GROUP #3
SPEED #4
165
PATTERN GROUP #3
SPEED #5
166
PATTERN GROUP #3
SPEED #6
167
PATTERN GROUP #3
SPEED #7
168
PATTERN GROUP #3
NUMBER OF CYCLES
0 / 1 00FF
0001 ∼ 00FF: 1 ∼ 255
1
