Toshiba G3 TOSVERT-130 - Page 47

46
Register Function / Title Bank Mask Adjustment Range Multiplier
169
PATTERN GROUP #4
SPEED #0
1 00FF 0000: Skip (0) 1
16A
PATTERN GROUP #4
SPEED #1
0001 ∼ 000F: Speeds 1 ∼ 15
16B
PATTERN GROUP #4
SPEED #2
16C
PATTERN GROUP #4
SPEED #3
16D
PATTERN GROUP #4
SPEED #4
16E
PATTERN GROUP #4
SPEED #5
16F
PATTERN GROUP #4
SPEED #6
170
PATTERN GROUP #4
SPEED #7
171
PATTERN GROUP #4
NUMBER OF CYCLES
0 / 1 00FF
0001 ∼ 00FF: 1 ∼ 255
1
172
SPEED #1 CONTINUE
MODE
1 00FF 0000: Count in seconds from time of
activation (0)
0001: Count in minutes from time of
activation (1)
0002: Count in seconds from speed
reach (2)
0003: Count in minutes from speed
reach (3)
0004: Non-stop (continue until
STOP command) (4)
0005: Continue until next step
command (5)

173 < 4
SPEED #1 DRIVE
TIME
1 FFFF
0000 ∼ 1F40 (0 ∼ 8000)
1
174
SPEED #2 CONTINUE
MODE
1 00FF Same as SPEED #1 CONTINUE
MODE

175 < 4
SPEED #2 DRIVE
TIME
1 FFFF
0000 ∼ 1F40 (0 ∼ 8000)
1
176
SPEED #3 CONTINUE
MODE
1 00FF Same as SPEED #1 CONTINUE
MODE

177 < 4
SPEED #3 DRIVE
TIME
1 FFFF
0000 ∼ 1F40 (0 ∼ 8000)
1
178
SPEED #4 CONTINUE
MODE
1 00FF Same as SPEED #1 CONTINUE
MODE

179 < 4
SPEED #4 DRIVE
TIME
1 FFFF
0000 ∼ 1F40 (0 ∼ 8000)
1
17A
SPEED #5 CONTINUE
MODE
1 00FF Same as SPEED #1 CONTINUE
MODE

17B < 4
SPEED #5 DRIVE
TIME
1 FFFF
0000 ∼ 1F40 (0 ∼ 8000)
1
17C
SPEED #6 CONTINUE
MODE
1 00FF Same as SPEED #1 CONTINUE
MODE

17D < 4
SPEED #6 DRIVE
TIME
1 FFFF
0000 ∼ 1F40 (0 ∼ 8000)
1
17E
SPEED #7 CONTINUE
MODE
1 00FF Same as SPEED #1 CONTINUE
MODE

17F < 4
SPEED #7 DRIVE
TIME
1 FFFF
0000 ∼ 1F40 (0 ∼ 8000)
1
180
SPEED #8 CONTINUE
MODE
1 00FF Same as SPEED #1 CONTINUE
MODE

181 < 4
SPEED #8 DRIVE
TIME
1 FFFF
0000 ∼ 1F40 (0 ∼ 8000)
1
