Register Function / Title Bank Mask Adjustment Range Multiplier
98
BINARY INPUT STD OR
ADJUSTABLE
0 / 1 0001 0000: Standard (0)
0001: Adjustable (1)

99 1
BINARY REF
SETTING POINT #1
0 / 1 00FF
0000 ∼ 0064 (0 ∼ 100)
1
9A
BINARY REF POINT
#1 FREQUENCY
0 / 1 FFFF
-Fmax ∼ Fmax
0.02
9B
BINARY REF
SETTING POINT #2
0 / 1 00FF
0000 ∼ 0064 (0 ∼ 100)
1
9C
BINARY REF POINT
#2 FREQUENCY
0 / 1 FFFF
-Fmax ∼ Fmax
0.02
9D
JOG RUN FREQUENCY
0 / 1 FFFF
0000 ∼ 07D0 (0.00 ∼ 20.00)
0.01
9E Other
than 0
JOG STOP
METHOD
0 / 1 00C0 0000: Decelerated stop (0)
0040: Coast stop (1)
0080: DC injection stop (2)

9F
PRESET SPEED
SELECTION
0 / 1 000F
0000 ∼ 000F (0 ∼ 15)
1
A0 ∼ FF
Reserved
   
100 Other
than 0
PRESET SPEED
MODE
ACTIVATION
0 / 1 0004 0000: Deactivated (0)
0004: Activated (1)

101
PRESET SPEED
#1 FREQUENCY
1 FFFF
LL ∼ UL
0.01
102
PRESET SPEED
#1 OPERATING
MODE
1 040C 0004: (0)
0000: (1)
000C: (2)
0008: (3)
0404: (4)
0400: (5)
040C: (6)
0408: (7)
1
103 2 or
higher
PRESET SPEED
#2 FREQUENCY
1 FFFF
LL ∼ UL
0.01
104
PRESET SPEED
#2 OPERATING
MODE
1 040C Same as PRESET SPEED #1
OPERATING MODE
1
105 3 or
higher
PRESET SPEED
#3 FREQUENCY
1 FFFF
LL ∼ UL
0.01
106
PRESET SPEED
#3 OPERATING
MODE
1 040C Same as PRESET SPEED #1
OPERATING MODE
1
107 4 or
higher
PRESET SPEED
#4 FREQUENCY
1 FFFF
LL ∼ UL
0.01
108
PRESET SPEED
#4 OPERATING
MODE
1 040C Same as PRESET SPEED #1
OPERATING MODE
1
109 5 or
higher
PRESET SPEED
#5 FREQUENCY
1 FFFF
LL ∼ UL
0.01
10A
PRESET SPEED
#5 OPERATING
MODE
1 040C Same as PRESET SPEED #1
OPERATING MODE
1
10B 6 or
higher
PRESET SPEED
#6 FREQUENCY
1 FFFF
LL ∼ UL
0.01
10C
PRESET SPEED
#6 OPERATING
MODE
1 040C Same as PRESET SPEED #1
OPERATING MODE
1
10D 7 or
higher
PRESET SPEED
#7 FREQUENCY
1 FFFF
LL ∼ UL
0.01
10E
PRESET SPEED
#7 OPERATING
MODE
1 040C Same as PRESET SPEED #1
OPERATING MODE
1
