Toshiba G3 TOSVERT-130 - Page 37

36
Register Function / Title Bank Mask Adjustment Range Multiplier
60
“OUT” CONTACTS HOLD
TIME
0 / 1 00FF
0001 ∼ 0064 (1 ∼ 100)
1
61
LOW SPEED SIGNAL
OUTPUT FREQ
0 / 1 FFFF
0 ∼ Fmax
0.01
62
ACC/DEC COMPLETE
DETECT BAND
0 / 1 FFFF
0 ∼ Fmax
0.01
63
SPEED REACH MAXIMUM
FREQUENCY
0 / 1 FFFF
0 ∼ Fmax
0.01
64
SPEED REACH MINIMUM
FREQUENCY
0 / 1 FFFF
0 ∼ Fmax
0.01
65
COMMERCIAL POWER/INV
SWITCHING OUTPUT
0 / 1 00C0 0000: OFF (0)
0040: Auto switch on trip (1)
0080: At COMMERCIAL POWER/INV
SWITCH FREQ (2)
00C0: Both (1) and (2) (3)

66 2, 3
COMMERCIAL
POWER/INV
SWITCH FREQ
0 / 1 FFFF
0 ∼ Fmax
0.01
67
“FP” OUTPUT TERMINAL
PULSE FREQUENCY
0 / 1 0003 0000: 48f (0)
0001: 96f (1)
0002: 360f (2)

68
RR INPUT SPECIAL
FUNCTION SELECT
0 / 1 00E0 0000: Standard (0)
0040: Fmax (1)
0080: TACC/TDEC mult. (2)
00C0: VB mult. Factor (3)
0020: CL mult. Factor (4)

