P9 ASD Installation and Operation Manual 257
User Notification Codes
The User Notification codes appear in the top right corner of the Frequency Command screen while the
associated function is active.
User Notification codes notify the user of active functions that are usually only momentary under normal
conditions and are active for the duration of activation only.
User notification events are not error conditions and only convey active system functions to the user.
Table 13. User Notification Codes.
LED Function Description
Atn Autotune active Atn indicates that the Autotune function is active.
dbOn DC Braking
This code conveys the DC Injection function being carried out. The display shows db when
braking and shows dbOn when the motor shaft stationary function is being carried out.
