User’s Manual 6-13
Power
To remove a discharged battery, follow the steps below.
1. Save your work.
2. Turn the computer’s power off. Make sure the Power indicator is off.
3. Remove all cables connected to the computer.
4. Close the LCD display panel and turn the computer upside down.
5. Slide the battery safety lock towards the release ( ) position to make
the battery release latch movable.
Figure 6-1 Releasing the battery pack (1)
6. Slide the battery release latch (➀) to free the battery pack for removal
(➁), then slide out the battery pack.
Figure 6-2 Releasing the battery pack (2)
To install a battery, follow the steps below.
7. Insert the battery pack (➀).
Battery pack
Battery safety lock
Battery pack
Battery release
latch
To Next Page
