9-20 User’s Manual
Optional Devices
Disconnecting USB floppy disk drive
When you have finished using the floppy disk drive, follow the procedures
below to disconnect it:
1. Wait for the indicator light to go out to make sure all floppy disk activity
has stopped.
2. Click the Safely Remove Hardware icon on the Task Bar.
3. Click floppy disk drive device that you want remove.
4. Pull the floppy disk drive’s USB connector out of the computer’s USB
port.
External monitor
An external analog monitor can be connected to the external monitor port
on the computer. The computer supports WXGA+ and WUXGA video
modes. To connect a monitor, follow the steps below.
1. Turn the computer off.
2. Connect the monitor cable to the external monitor port and tighten the
screws on the left and right hand side.
Figure 9-20 Connecting the monitor cable to the external monitor port
If you connect the floppy disk drive after turning on the computer, it will
take about 10 seconds for the computer to recognize the drive. Do not
disconnect and reconnect before 10 seconds has elapsed.
If you disconnect the floppy disk drive or turn off the power while the
computer is accessing the drive you may lose data or damage the floppy
disk or the drive.
Monitor cable
External monitor
port
The computer is equipped with either an HDMI or D-Video out port.
