User’s Manual 2-7
The Grand Tour
■ Do not connect any cable other than a LAN cable to the LAN jack. It
could cause damage or malfunction.
■ Do not connect the LAN cable to a power supply. It could cause
damage or malfunction.
Link indicator
(green)
This indicator glows green when the computer is
connected to a LAN and the LAN is functioning
properly.
LAN active
indicator (orange)
This indicator glows orange when data is being
exchanged between the computer and the LAN.
Universal
Serial Bus
(USB 2.0) ports
Two Universal Serial Bus ports are on the back
side. Refer to Left side section, for details.
External monitor
port
This external monitor port lets you connect an
external video display.
D-Video out port This D-Video out port lets you transfer 525i
(480i), 525p (480p), 1125i (1080i) or 750p (720p)
data to external devices. Refer to TV section in
Chapter 9, Optional Devices.
HDMI out port HDMI out port can connect with Type A
connector HDMI cable.
One HDMI cable can send and receive video,
audio and control signals.
The computer is equipped with either an HDMI or D-Video out port.
S-Video out port This S-Video out port lets you transfer NTSC or
PAL data to external devices. Refer to TV section
in Chapter 9, Optional Devices.
