Apx. C Pin Assignments Appendices
C.21 CN2000 Touch Pad Connector (12-Pin)
Table C-19 Touch Pad connector pin assignments (12-Pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 /IM_CLK_CN I/O 2 /IM_CLK_CN I/O
3 /IM_DAT_CN I/O 4 /IM_DAT_CN I/O
5 /LEFT_CN I 6 /LEFT_CN I
7 /RIGHT_CN I 8 /RIGHT_CN I
9 PGND - 10 PGND -
11 NC - 12 +V5S_CN -
G1 PGND - G2 PGND -
C.22 CN2002 LED Connector (24-Pin)
Table C-22 LED connector pin assignments (24-Pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 +V3A_CN - 2 /DCIN_OLED#_CN O
3 /DCIN_GLED#_CN O 4 /BAT0_OLED#_CN O
5 /BAT0_GLED#_CN O 6 +V5S_CN -
7 +V5S_CN - 8 /IDELED#_CN O
9 +V3S_CN - 10 +V3S_CN -
11 /WLON_LED#_CN O 12 +V3_CN -
13 /PWR_OLED#_CN O 14 /PWR_GLED#_CN O
15 /IM_CLK_CN I/O 16 /IM_DAT_CN I/O
17 /IR_TX_CN O 18 /IR_RX_CN I
19 /IR_SD_CN I 20 PGND -
21 PGND - 22 PGND -
23 PGND - 24 PGND -
G1 PGND - G2 PGND -
Satellite A60/ Pro A60 Maintenance Manual C-1
