The Grand Tour
IPT2000-series Telephones
4
Strata CIX and CTX IPT/DKT Telephone 12/05
Liquid Crystal Display
Your Liquid Crystal Display (LCD) (shown below) shows:
• Desk Clock and Calendar in idle mode
• Call Duration during an outside call
• Operational, Advisory, and Notification messages
Note The IPT and DKT soft keys perform the same functions. This manual uses the
IPT soft keys (SK) to refer to the soft keys on all telephones. For example, if an
instruction references
SK1, this means use the first soft key (from left to right)
on the IPT.
SK2, SK3 and SK4 equate to the second, third and fourth soft keys
on the IPT or Page, Scroll and Feature on the DKT.
LCD Control Buttons/Soft Keys
There are two types of LCD button functions: LCD Control Buttons and Soft Keys.
SK1, SK2, SK3 and SK4 represent the LCD soft keys in this manual.
When the Soft Key prompts appear on the LCD, the LCD Control Button just below
the prompt offers access to that feature. See
“Using Your LCD” on page 31 for more
information.
• SK1 is generally used as a Soft Key.
• Pressing
SK2 switches you from the Call Forward (CF) display to the User Name
display.
• Pressing SK3 advances you through information.
•
SK4 will be used in the future.
7499
AUG 08 MON 03:56
CF-ALL 202-203+
Mode Page Scroll Feature
DKT & IPT1020-SD Telephone LCD
IPT2010/2020-SD Telephone LCD
LCD Control
Buttons/Soft Keys
SK1
(Mode)
SK2
(Page)
SK3
(Scroll)
SK4
(Feature)
MY EXTR INTR DIAL
SELECT DIRECTORY
