Toshiba TOSVERT VF-S15 series Manual

E6581911
- 1 -
Introduction
Thank you for purchasing TOSVERT VF-S15 / VF-AS3 series.
Before using CANopen
®
communication function, carefully read this function manual in order to completely and
correctly utilize its excellent performance.
After reading this function manual, please keep it handy for future reference.
For details of its general handling, see an instruction manual attached with the option unit.
･TOSVERT VF-S15 Instruction Manual ･･･････････････････････････････････ E6581611
･TOSVERT VF-S15 Communications Function Instruction Manual ･･･････････ E6581913
･VF-S15 Option Adapter Instruction Manual ･･････････････････････････････････････ E6581838
･TOSVERT VF-AS3 Instruction Manual ･･･････････････････････････････････ E6582062
･TOSVERT VF-AS3 Communications Function Instruction Manual ･･･････････ E6582143
* CANopen
®
and CiA
®
are a registered trademark of CAN in Automation.
Handling in general
Danger
Mandatory
Do not connect or disconnect a network cable while the drive power is on.
It may lead to electric shocks or fire.
See the instruction manual attached with the option unit for cautions the handling.
Otherwise, it may lead to electric shocks, fire, injuries or damage to product.
Network control
Warning
Prohibited
Do not send the value out of the valid range to network variables.
Otherwise, the motor may suddenly start/stop and that may result in injuries.
Do not use application of writing into same parameter more than 100,000 times. The Life
of EEPROM is approximately 100,000 times. Do not write to the user parameter area of
inverter by SDO to avoid EEPROM broken. See "5.2.Manufacturer specific profile" in
detail.
Mandatory
Use an additional safety device with your system to prevent a serious accident due to the
network malfunctions. Usage without an additional safety device may cause an accident.
Warning
Mandatory
Set up “Communication error trip function (see below)” to stop the drive when the
network is deactivated by an unusual event such as tripping, an operating error, power
outage, failure, etc.
- Communication error trip time, Operation at communication error
(Refer to “7.4 Communication disconnection detection function” for details)
Deactivated the drive may cause an accident, if the “Communication error trip function”
is not properly set up.
Make sure that the operation signals are STOP before resetting drive’s fault. The motor
may suddenly start and that may result in injuries.
Notes on operation
Notes
When the control power is shut off by the instantaneous power failure, communication
will be unavailable for a while.
