Toshiba TOSVERT VF-S15 series - Page 29

E6581911
- 28 -
Error
code
*1
Meaning
Drive
trip code
*2
Drive
error
name
Drive condition
0x3120
Mains under-voltage
0x1E
up1
Undervoltage fault (main circuit)
0x3130
Phase failure
0x08
eph1
Ground fault
0x3310
Output over-voltage
0x09
0x0F
0x47
epho
olr
e-39
Output phase failure
Dynamic braking resistor overload trip
Auto-tuning error (PM motor)
0x4130
Ambient temperature
0x4A
e-42
Cooling fan fault [VF-AS3]
*3
0x4210
Excess temperature
device
0x0D
0x10
0x3E
ol1
oh
ol3
Drive overload
Overheat
Main module overload
0x5140
Battery failure
0x4C
e-44
Battery of panel failure [VF-AS3]
*3
0x5500
Unit internal fault
0x50
e-48
A6 Brake Unit internal fault [VF-AS3]
*3
0x5530
Control EEPROM failure
0x12
0x13
0x14
0x29
eep1
eep2
eep3
etyp
EEPROM fault 1
EEPROM fault 2
EEPROM fault 3
Drive type error
0x6100
Internal software
0x33
0x37
e-19
e-23
CPU communication error
Optional unit fault 2 [VF-S15],
Option fault (slot A) [VF-AS3]
0x7300
Sensor
0x2E
0x32
0x40
oh2
e-18
e-32
Thermal fault stop command from
external device
Analog input break detection fault
PTC fault
0x7310
Speed
0x2D
e-13
Over speed fault
0x7500
External communication
fault
0x36
0x46
0x4b
e-22
e-38
e-43
Embedded Ethernet fault [VF-AS3]
*3
Communication time-out of A6 Brake Unit
Communication time-out (embedded Ethernet)
[VF-AS3]
*3
0x7510
Serial interface No. 1
0x18
err5
Communication error
0x7520
Serial interface No. 2
0x1B
err8
Optional unit fault 1
0x8331
Torque fault
0x2F
0x34
sout
e-20
PM Step-out
Over torque boost fault
0x8501
Servo lock failure
0x45
e-37
Servo lock fault
0x9000
External malfunction
0x11
0x58
e
e-99
Emergency stop
Trip for test [VF-AS3]
*3
0xFF00
Additional functions
- generic error
0x54
004D
etn1
e-45
Auto-tuning error
GD2 auto-tuning error
0xFF03
Device specific
- generic error
0x1D
0x3B
0x49
0x57
uc
prf
utc3
e-27
Low-current operation Trip
Safe torque switching check alarm
Undertorque / Undercurrent [VF-AS3]
*3
Power removal fault [Only VF-S15]
*1: Error code: same information as lower 16-bit of the pre-defined error code field (1003h sub-index 01h)
*2: Drive trip code: Drive internal error code
*3: These errors are for VF-AS3.
