Unified Controller Vm series TC-net 100 (TNB) Module Instruction Manual
25
Select the Extended card TNB module.
Select [TNB21] on extended card, when [Module parameters] is selected
from [File (F)] on the menu bar, the module parameter screen is displayed.
Figure 3-9 Extension card registration screen
Table 3-5 Registerable expansion TNB card
<Single Configuration>
Card No. Model Name Remarks
50/52/53 TNB21 BUB11
TNB22 BUB11
<Multi Configuration>
Card No. Model Name Remarks
53 TNB21 BUB21
TNB22 BUB21
