XLS, XL, 3000 AND 2000 OWNER’S MANUAL | PRODUCT SPECIFICATIONS
To order optional accessories, please go to TotalGymDirect.com 4
Product Specications (XLS shown)
Hitch Pin
(Connected with a lanyard to
height adjustment column)
Handle
Inner Rail
Front Crossbar
Support Column
Squat Stand
(optional)
Back Crossbar
Rollers
Center Support Rail
Outer Rail
LEG PULL ACCESSORY
LENGTH
Folded ................................. 51.5”
In Use .................................... 90”
HEIGHT
Folded ............................... 8.875”
In Use .................................... 43”
Width .................................. 18.5”
Weight .............................. 68 lbs.
Maximum User Weight ..... 400 lbs.
Cable
Safety
Hole
Height Adjustment
Slide Mechanism
(Includes the Height
Adjustment Lever)
Leg Pull Bracket
Glideboard
Squat Stand
Receptacles
Storage Hole
Hole for optional Weight Bar
SAFETY HITCH PINS (SHORT) 2
• 1 in Literature Pack. Use in storage hole when storing unit.
• 1 connected with a lanyard to height adjustment slide
mechanism. Use in safety hole during exercise.
Total Gym
Training Deck
(optional)
Wing Attachment
(optional)
Requires 2 long
hitch pins
Optional Accessories Available for Purchase Weight Bar accessory also available.
Clip
O-ring
Pulley/D-Ring
Assembly
Foot Harness (2)
Rope
PRESS UP BARS
ABCRUNCH
DIP BARS
TOTAL GYM CYCLO TRAINER
Requires 2 short hitch pins
Requires
2 short
hitch pins
WARNING
LABEL 1
WARNING
LABEL 2
Pulley Assembly
WARNING
LABEL 3
WARNING
LABEL 4
WARNING
LABEL 4
WARNING
LABEL 5
CAUTION
LABEL 1
CAUTION
LABEL 2
CAUTION
LABEL 3
PILATES ACCESSORY KIT
Pilates Toe Bar
24-inch leg pulley
rope extension
Foot
Harness (2)
