10 SWITCHES AND LEVERS
en‐27
WARNING
• Alwaysoperatetheattachmentleversfromanormalseatedposition.
• IftheOPSisactivated,fullyreleasetheacceleratorpedal,returnallleverstotheneutral
positionandreturntothenormalseatedpositiontodeactivatetheOPS.
• Afterthe OPSisactivated,ifyou returnto thenormalseated positionwhile thelever(s)
areoperated,theOPSwillnotbedeactivatedandtheforkswillnotmoveduetothere
turntoneutralfunction.Alwaysreturnallleverstotheneutralpositionbeforereturningto
theseatwhendeactivatingtheOPS.
10.18.6Hornswitch
(1)
(1)Hornswitch
Pressthisswitchtosoundthehorn.
10.19Joystick(Option)
10.19.1Directioncontrollever
(1)
(2)
(1)Forwardtravel
(2)Reversetravel
Shift lever to change the travel direction
betweenforwardandreverse.
ForwardtravelPushtheleverforward
ReversetravelPulltheleverbackward
The neutral position is halfway between the
forwardandbackwardposition.
Forwardandreversetravelspeedcanbead
justedbytheamounttheacceleratorpedalis
depressed.
CAUTION
• Alwaysoperatethecontrolleverfromanormalseatedposition.
• Theenginecannotbestartedunlessthedirectioncontrolleverisintheneutralposition.
• Stopthetruckbeforeshiftingbetweenforwardandreverse.
NOTICE
• TorestartpoweredtravelaftertheactivationofOPS,releasetheacceleratorpedal,return
the direction control lever to the neutral position and sit in the seat. Sitting in the seat
withoutreturningthedirectioncontrollevertotheneutralpositionwillnotallowpowered
travel.
• Thepositionofthedirectioncontrollevermayvarydependingonthetruckspecifications.
10.19.2Loadhandlinglever
(1)
(3)
(2)
(4)
(1)Forwardtilt
(2)Backwardtilt
(3)Lift
(4)Lower
Lever to tilt the mast forward and backward
andliftandlowertheforks.
ForwardtiltPushtheleverforward
BackwardtiltPulltheleverbackward
Theforwardorbackwardtiltingspeedcanbe
adjustedbytheamounttheacceleratorpedal
is depressed and the amount the lever is
moved.
LiftPushthelevertotheright
LowerPushthelevertotheleft
The lifting speed can be adjusted by the
amount the accelerator pedal is depressed
andtheamounttheleverismoved.
Theloweringspeedcanbeadjustedonlyby
theamounttheleverismoved.
WARNING
• Alwaysoperatetheloadhandlingleverfromanormalseatedposition.
• IftheOPSisactivated,fullyreleasetheacceleratorpedal,returnallleverstotheneutral
positionandreturntothenormalseatedpositiontodeactivatetheOPS.
• Afterthe OPSisactivated,ifyou returnto thenormalseated positionwhile thelever(s)
areoperated,theOPSwillnotbedeactivatedandtheforkswillnotmoveduetothere
turntoneutralfunction.Alwaysreturnallleverstotheneutralpositionbeforereturningto
theseatwhendeactivatingtheOPS.
10
