12 INSTRUMENT
en‐36
12INSTRUMENT
12.1Combinationmeter
Gaugesandwarninglampsonthecombinationmeterareasfollows:
Gasolineenginemodels
(1) (2) (3)
(5) (10)(9)(8)(7) (13)(12)(11)
Dieselenginemodels
(4) (5) (6) (7) (8) (9) (10) (11) (12) (13)
(1)
(2) (3)
(1) Watertemperaturegauge
(2) Hourmeter
(3) Brakeindicator(Option:OKmonitor)
(4) Sedimenter/fuelfilterwarning(Dieselenginemodels)
(5) Fuelgauge
(6) Glowindicator(Dieselenginemodels)
(7) Malfunctionindicatorlamp
(8) Engineoilpressurewarning
(9) Chargingsystemwarning
(10) OPSindicator
(11) Diagnosisindicator
(12) Aircleanerwarning(Option:OKmonitor)
(13) Coolingwaterlevelwarning(Option:OKmonitor)
12.1.1Warninglampcheck
(1)Keyswitchon
1. Checkifall warningindicatorsilluminate
whenthekeyswitchisturnedon.
2. If any lamp does not come on, ask the
Toyotadealerforaninspection.
CAUTION
The glow indicator lamp illuminates for a second when the engine coolant temperature ex
ceeds50°C(22°F)(fordieselenginemodels).
