13 LPG DEVICE ﴾OPTION﴿
en‐49
13.2LPGrelatedparts
(1)
(2)
(3)
(1)Outflowvalve
(2)Inflowvalve
(3)Pipevalve
Outflowvalve
ThisvalvecontrolstheflowofLPGfuelfrom
theLPGtanktotheregulator.
Toopenthevalveturnitcounterclockwise
Toclosethevalveturnitclockwise
Inflowvalve
LPG is filled in the tank through this valve.
ThetankmustbefilledbyanLPGfillingsta
tionattendant.Besurethatthisvalveisshut
tightlyatalltimesduringuse.
Pipevalve
When the fuelhose needs to be disconnec
ted for tank replacement, etc., close this
valvetopreventtheliquidfromrunningoutof
thehose.
Toopenthevalveturnitcounterclockwise
Toclosethevalveturnitclockwise
(1)
(1)ReliefValve
ReliefValve
This valve prevents explosion that might be
caused whenthe LPG pressure risesabove
a normal level or when the hose becomes
deteriorated.
Swingtype
Swingdowntype(Option)
LPGtankbracket
LPG tank is securely locked on the tank
bracketbythetankbracketstopper.
For swingdown type, LPG tank can be
loweredattheangleupto65°.
(1)
(2)
(1)Tankbracketstopper
(2)65°
