13 LPG DEVICE ﴾OPTION﴿
en‐48
13LPGDEVICE(OPTION)
NamesofLPGdevicecomponents
LPGtank
(1) (2)
(3) (6)(5)(4)
Regulator
(9)
(7)
(8)
(1) Tankband (6) Tankbracket
(2) Setpin(upperside) (7) Filter
(3) Tankbracketstopper (8) Mainsolenoidvalve
(4) LPGtank (9) Regulator
(5) Tankclamp
13.1Switches
Fuelchangeoverswitch(GasolineLPGmodels)
(1)
(1)Fuelchangeoverswitch
Thisisaswitchtoselectthetypeoffueltobe
used(gasolineorLPG).
OFF  Horizontal position (Fuel is not sup
pliedandtheenginedoesnotstartup).
LPGLowerposition
GASOLINEUpperposition
NOTICE
• If the key switch is turned off, fuel is not supplied to the engine even when the fuel
changeoverswitchispositionedatLPGorGASposition.
LPGwarningswitch(Option)
(1)
(1)LPGwarningswitch
When the LPG level inside LPG tank gets
low, the warning lamp will come on and the
warningsoundwillnotifytheoperator.
When the fuel warning system operates,
pushtheswitchtostopthewarningsound.
ThelampremainsonuntilLPGisrefuelled.
NOTICE
• Oncethefuelwarningsystemsounds,alwaysrefuel.
• Itispossibletotravel forapproximately1.5 minutes(350m [1148ft]) afterthewarning
systemisoperated.Thefeasibledrivetimevariesdependingonthetypeofoperationbe
ingperformed,ambienttemperatureandLPGcomposition,etc.
