12 INSTRUMENT
en‐41
12.1.12.3Brakeindicator
▪ The brake indicator lamp comes on
when the parking brake is applied. (It
goes off when the parking brake is re
leased.)
▪ Ifthewarningremainsonevenafterthe
parking brake is released, ask the
Toyotadealerforaninspection.
CAUTION
• Beforestartingthetruck,alwaysreleasetheparkingbrakeleverandcheckthatthelamp
goesoff.
12.1.13Timingbeltcautionfunction
(Dieselenginemodels)
(1)
(2)
(1)Diagnosisindicator
(2)Hourmeter
When the engine timing belt is used over
4000hours,thecombinationmeterindicates
that thetimingbelt needs to bereplacedby
thefollowingbehavior:
▪ Diagnosis indicator  Illuminates con
tinuously after the key switch is turned
on.
▪ Hour meter  Displays "bELT" for 10
seconds after the key switch is turned
on.
Shouldthe aboveconditionsoccur, parkthe
truck in a safe location, apply the parking
brakeandcontacttheToyotadealerimmedi
ately.
CAUTION
• Oncethe timingbeltcautionfunctionis on,have thetimingbelt replacedby theToyota
dealerimmediately.Failuretodosocouldcauseseriousdamagetotheengine.
NOTICE
The diesel engine timing belt needs to be replaced after every 4000 hours of use. It also
needstobereplacedwhentheSAS/OPScontrollerorthecombinationmeterisreplaced.
12.2Multifunctiondisplay(Option)
(2)
(1)
(3) (4) (5)
MODE
(1) Multiplescreendisplayarea
(2) Switch(a):Lowspeedsettingswitch/Downswitch
(3) Switch(b):Modeselectswitch/Leftswitch
(4) Switch(c):Rightswitch
(5) Switch(d):Metermodeselectswitch/Enterswitch
NOTICE
• Alwaysoperatetheswitchpanelwhenthetruckisstopped.
• Alwayspressswitcheswithyourfingertips.Ifasharppointedtoolisused,theswitchmay
bedamaged.
12.2.1Startscreen
MODE
The start screen is displayed for 1 second
afterthekeyswitchisturnedon.
