11 BODY COMPONENTS
en‐34
(1)Hooddamperlock
Closing
1. Lift up the engine hood and press the
hooddamperlocktoreleasethelock.
2. Closetheenginehoodgently,andpress
downonthehooduntilyouhearaclick
ingsound.
3. Returntheseatandarmresttothenor
malposition.
11.6Drawbar
(1)Drawbar
The draw bar is located at the back of the
counterweight, and is used to pull the truck
shouldits tiresdropinto agutter orbecome
stuckinmud.
It can also be used for loading the forklift
onto a truck or another truck. The draw bar
should not be used for towing the forklift or
fortowinganothertruckusingtheforklift.
11.7Liftingpoints
(1)
(1)Liftingpoints
Lifting points are located on the outer mast
andtheoverheadguard.
WARNING
• Whenliftingthetruckatliftingpoints,besuretousecablethathasplentyofstrength.
11.8Overheadguard
When properly maintained, the overhead
guardwillhelpprotecttheoperatorfromfall
ingobjects.
11.9Loadbackrestextension
Whenproperlymaintained,theloadbackrest
extensionwillhelpstabilizetheloadandpre
ventpartsofaloadfromfallingbackintothe
operator’scompartment.
11.10Mast
The mast uses special steel and precision
bearings to make your Toyota lift truck reli
ableandeconomical.
Themastismountedtothefrontofthetruck.
Hydraulic cylinders are used to tilt the mast
forward and backward. Hydraulic cylinders
andchainsareusedtoraisethecarriageand
attachments.
WARNING
• Themastisdesignedforliftingloadsnotpeople.Donotuseyourforkliftinplaceofanel
evatingworkplatform.
• Neverplaceanypartofyourbodyinanypartofthemast,thecarriageorattachment.
