Chapter 13
13. 11. Control LEDs
The router LEDs indicate router activities and behavior. You can turn on or turn off the
router from the management web-page.
¾ To turn on or off the LEDs:
• Press the LED button on the router about 2 seconds to turn on or off the
LEDs.
• Visit http://tplinkwifi.net, and log in with the username and password you’ve set
for the router. Click the LED icon on the top right of the page.
¾ To turn off LEDs during Night Mode Period:
1 ) Visit http://tplinkwifi.net, and log in with the username and password you set
for the router.
2 ) Go to Advanced > System Tools > System Parameters.
3 ) In the LED Control section, select the Enable Night Mode checkbox.
4 ) Specify a time period in the Night Mode Period according to your need, and the
LEDs will be off during this period.
5 ) Click Save to make the settings effective.
