73
Chapter 11
Customize Your Network Settings
address, so here enters 172.30.30.1.
Subnet Mask: Determines the destination network with the
destination IP address. If the destination is a single IP address,
enter 255.255.255.255; otherwise, enter the subnet mask of
the corresponding network IP. In the example, the destination
network is a single IP, so here enters 255.255.255.255.
Default Gateway: The IP address of the gateway device to which
the data packets will be sent. This IP address must be on the
same subnet with the router’s IP which sends out the data. In
the example, the data packets will be sent to the LAN port of
Router 2 and then to the Server, so the default gateway should
be 192.168.0.2.
Interface: Determined by the port (WAN/LAN) that sends out
the data packets. In the example, the data is sent to the gateway
through the LAN port, so LAN should be selected.
Description: Enter a description for this static routing entry.
6. Click OK to save the settings.
7. Check the System Routing Table below. If you can find the
entry you set in the System Routing Table, the static routing
is set successfully.
Open a web browser on your PC. Enter the company server’s IP
address to visit the company network.
Done!
