86
Chapter 15
Specify Your Network Settings
path regardless of other considerations. Normal internet usage does not require this
setting to be configured.
I want to:
Visit multiple networks and multiple servers at the same time.
For example, in a small office, my PC can surf the internet, but I also want to visit my
company’s server. Now I have a switch and another router. I connect the devices as
shown in the following figure so that the physical connection between my PC and my
company’s server is achieved. To surf the internet and visit my company’s network at
the same time, I need to configure the static routing.
Company’s server
My PC
Router 2Modem router
Switch
LAN: 192.168.1.1
192.168.1.100
LAN: 192.168.1.2
WAN: 172.30.30.100
172.30.30.1
WPS�ResetWIFI
USB LAN1 LAN2 LAN3
LAN4�WAN DSL
WPS�ResetWIFI
USB LAN1 LAN2 LAN3
LAN4�WAN DSL
How can I do that?
1. Make sure the routers use different LAN IP addresses on the same subnet. Disable
Router 2’s DHCP function.
2. Visit http://tplinkmodem.net, and log in with your TP-Link ID and the password you
set for the router.
3. Go to Advanced > Network > Static Routing. Select your current WAN Interface and
click Save.
4. Click Add to add a new static routing entry. Finish the settings according to the
following explanations:
