TP-Link Archer VR600 User Manual

55
Chapter 11 Network Security
5. Select a Service Type from the drop-down list and the following four fields will be
auto-populated. Select Custom when your desired service type is not listed, and
enter the information manually.
6. Specify the IP address(es) that this filtering rule will apply to.
7. Click Save.
Note: If you want to disable this entry, click the icon.
11. 3. Access Control
Access Control is used to block or allow specific client devices to access your network
(via wired or wireless) based on a list of blocked devices (Blacklist) or a list of allowed
devices (Whitelist).
Block or allow specific client devices to access my network (via
wired or wireless).
1. Visit http://tplinkmodem.net, and log in with the account you
set for the router.
2. Go to Advanced > Security > Access Control and enable
Access Control.
I want to:
How can I
do that?

TP-Link Archer VR600 Specifications

General

Ethernet WAN	Yes
SIM card slot	No
WAN connection type	RJ-45
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1300 Mbit/s
WLAN data transfer rate (second band)	300 Mbit/s
Output current	2 A
Output voltage	12 V
Power source type	AC
Antennas quantity	3
Antenna gain level (max)	23 dBi
VPN support	PPTP, L2TP, IPSec Passthrough
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2
Supported network protocols	IPv4, IPv6
RJ-11 ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	4
Product type	Tabletop router
Product color	Black, Silver
LED indicators	LAN, Power, WLAN
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45), Phone (RJ-11)
Certification	CE, FCC, RCM, RoHS
Package depth	240 mm
Package width	318 mm
Package height	71 mm
Package weight	1160 g
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	163.8 mm
Width	215.8 mm
Height	37.3 mm
