TP-Link Archer VR600 User Manual

80
Chapter 14 Specify Your Network Settings
14. 2. 1. Configure the RADVD Address Type
1. Visit http://tplinkmodem.net, and log in with the account you set for the router.
2. Go to Advanced > Network > LAN Settings.
3. Select IPv6 to configure IPv6 LAN parameters.
1 ) Select the RADVD address type to make the modem router assign IPv6 address
prefixes to hosts.
Note:
Do not select the Enable RDNSS and Enable ULA Prefix check boxes unless required by your ISP. Otherwise
you may not be able to access the IPv6 network. For more information about RDNSS and ULA Prefix, contact
our technical support.
2 ) Keep Site Prefix Type as the default value Delegated. If your ISP has provided a
specific IPv6 site prefix, select Static and enter the prefix.
3 ) Keep Prefix Delegated WAN Connection as the default value.
4. Click Save to make the settings effective.
14. 2. 2. Configure the DHCPv6 Server Address Type
1. Visit http://tplinkmodem.net, and log in with the account you set for the router.
2. Go to Advanced > Network > LAN Settings.
3. Select IPv6 to configure IPv6 LAN parameters.

TP-Link Archer VR600 Specifications

General

Ethernet WAN	Yes
SIM card slot	No
WAN connection type	RJ-45
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1300 Mbit/s
WLAN data transfer rate (second band)	300 Mbit/s
Output current	2 A
Output voltage	12 V
Power source type	AC
Antennas quantity	3
Antenna gain level (max)	23 dBi
VPN support	PPTP, L2TP, IPSec Passthrough
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2
Supported network protocols	IPv4, IPv6
RJ-11 ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	4
Product type	Tabletop router
Product color	Black, Silver
LED indicators	LAN, Power, WLAN
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45), Phone (RJ-11)
Certification	CE, FCC, RCM, RoHS
Package depth	240 mm
Package width	318 mm
Package height	71 mm
Package weight	1160 g
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	163.8 mm
Width	215.8 mm
Height	37.3 mm
