Mask: Displays the OUI address mask of the voice device.
Description: Displays the description of the OUI.
Configuration Procedure of Voice VLAN:
Step Operation Description
1 Configure the
link type of the
port
Required. On VLAN→802.1Q VLAN→Port Config page, configure the
link type of ports of the voice device.
2 Create VLAN Required. On VLAN→802.1Q VLAN→Port Config page, click the
Create button to create a VLAN.
3 Add OUI
address
Optional. On QoS→Voice VLAN→OUI Config page, you can check
whether the switch is supporting the OUI template or not. If not, please
add the OUI address.
4 Configure the
parameters of
the ports in voice
VLAN.
Required. On QoS→Voice VLAN→Port Config page, configure the
parameters of the ports in voice VLAN.
5 Enable Voice
VLAN
Required. On QoS→Voice VLAN→Global Config page, configure the
global parameters of voice VLAN.
