TP-Link NC220 User Manual

NC220
Day/Night Cloud Camera, 300Mbps Wi-Fi
2.3 Appearance Description
2.3.1 Front Panel
Figure 2-1 Front Panel
 Light Sensor: The camera has a built-in internal photodetector. It is used to identify day or
night.
 Microphone: The camera has a built-in internal microphone. This microphone is hidden in
the pinhole located on the front panel.
 System LED:
Status Indication
Flashing Red
The camera starts booting up.
Solid Red
The camera has boot up, but is not connected to any network.
Flashing Green
The camera is in firmware upgrade procedure.
Solid Green
The camera is connected to a network or is transferring data.
System LED
Microphone
Light Sensor
3

TP-Link NC220 Specifications

General

Type	IP security camera
PTZ control	-
Antenna type	Internal
Certification	CE, FCC
Placement supported	Indoor
Connectivity technology	Wired & Wireless
Form factor	Cube
Mounting type	Desk/Wall
Product color	White
LED indicators	Yes
Full HD	No
Maximum resolution	640 x 480 pixels
Video formats supported	H.264
Supported graphics resolutions	320 x 240
Minimum illumination	0.5 lx
Sensor type	CMOS
Optical sensor size	1/4 \
Effective sensor resolution	0.3 pixels
Digital zoom	4 x
Optical zoom	- x
Focal length range	2.8 - 3.85 mm
Security algorithms	WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Wi-Fi data rate (max)	300 Mbit/s
Supported network protocols	Bonjour, TCP/IP, DHCP, PPPoE, ARP, ICMP, FTP, SMTP, Samba, NFS, DNS, NTP, UPnP, HTTP, HTTPS, TCP, UDP
Interface	RJ-45
Ethernet LAN (RJ-45) ports	1
Audio system	1-way
Audio formats supported	AAC
AC input voltage	9 V
Power consumption (typical)	5.4 W
Sustainability certificates	RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Mac operating systems supported	Mac OS X 10.7 Lion

Weight and Dimensions

Depth	24 mm
Width	61 mm
Height	96 mm
