NC220
Day/Night Cloud Camera, 300Mbps Wi-Fi
Camera Name: The default value is the camera model. You can change it to an
easy-to-remember one. Camera name can contain up to 30 characters. It can only contain
digits, letters, space and .-_@'.
After your camera is registered successfully, you can go to www.tplinkcloud.com
to view it.
Sign Up for a TP-LINK Cloud Account
If you do not have a TP-LINK Cloud account, click Dont have an account? to sign up.
E-mail: Enter a valid E-mail address as your TP-LINK Cloud account. If you forget your
TP-LINK Cloud password, you can reset it via this E-mail address.
Username: Enter a username as your TP-LINK Cloud account. Username should contain
1-32 characters. It can only contain letters, digits and . -_.
Password: Enter a password for your TP-LINK Cloud account. Password should contain 6-20
characters. It can only contain letters, digits and .-_ ! @ # $,% ^& *.
Confirm Password: Enter the password again to confirm it.
Click Sign up to sign up for a TP-LINK Cloud account. After signing up successfully, you can add
your camera to this account. Click Back if you dont want to sign up.
3.3.5 Basic LED
The cameras LED is on by default. If you want to turn it off, just select Off.
16

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TP-Link NC220 and is the answer not in the manual?

TP-Link NC220 Specifications

General IconGeneral
TypeIP security camera
PTZ control-
Antenna typeInternal
CertificationCE, FCC
Placement supportedIndoor
Connectivity technologyWired & Wireless
Form factorCube
Mounting typeDesk/Wall
Product colorWhite
LED indicatorsYes
Full HDNo
Maximum resolution640 x 480 pixels
Video formats supportedH.264
Supported graphics resolutions320 x 240
Minimum illumination0.5 lx
Sensor typeCMOS
Optical sensor size1/4 \
Effective sensor resolution0.3 pixels
Digital zoom4 x
Optical zoom- x
Focal length range2.8 - 3.85 mm
Security algorithmsWEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology10/100Base-T(X)
Wi-Fi data rate (max)300 Mbit/s
Supported network protocolsBonjour, TCP/IP, DHCP, PPPoE, ARP, ICMP, FTP, SMTP, Samba, NFS, DNS, NTP, UPnP, HTTP, HTTPS, TCP, UDP
InterfaceRJ-45
Ethernet LAN (RJ-45) ports1
Audio system1-way
Audio formats supportedAAC
AC input voltage9 V
Power consumption (typical)5.4 W
Sustainability certificatesRoHS
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 90 %
Operating relative humidity (H-H)10 - 90 %
Mac operating systems supportedMac OS X 10.7 Lion
Weight and Dimensions IconWeight and Dimensions
Depth24 mm
Width61 mm
Height96 mm
