TP-Link NC220 User Manual

NC220
Day/Night Cloud Camera, 300Mbps Wi-Fi
Chapter 2 Introduction
Thanks for choosing the NC220 Day/Night Cloud Camera, 300Mbps Wi-Fi!
2.1 Overview
NC220 is a versatile solution for home & office monitoring to keep an eye on your home, kids or
workplace; whatever it is that you care for most.
NC220 has a complete system with a built-in CPU and web server that transmits high quality video
images, which can fully meet the need of your small office or home’s security and surveillance.
NC220 is an affordable and fully scalable surveillance camera. Because the camera can be added
to your existing local area network (LAN) with a stable high speed Wi-Fi connection, you will
potentially save a lot from unnecessary cabling. With wireless extender feature, it can also be
used as a Wi-Fi range extender to easily expand your Wi-Fi network.
NC220 can be accessed remotely, and controlled from any computer over your local network or
through the Internet via a web browser. NC220 is a complete and cost-effective home or office
security solution for it comes with remote monitoring and motion detection feature.
NC220 is a cloud-based Wi-Fi video monitoring device with free live streaming and remote viewing,
which makes it easy to stay connected with what you care most wherever you are. You can view
and manage your camera from anywhere over the Internet through the TP-LINK Cloud website or
through the tpCamera app for iOS and Android.
2.2 Main Features
• Monitor your home or office remotely with web-based management page
• iOS and Android app for remote viewing and management with TP-LINK Cloud
• TP-LINK Cloud (www.tplinkcloud.com
) access for easy viewing and management
• Email or FTP notification triggered by motion detection
• Supports wireless 802.11b/g/n with speed up to 300Mbps
• Wireless connectivity compliant with WPS button
• Instantly eliminates the dead zones and expand your home’s wireless network
• Ethernet port for wired connectivity
• UPnP support for network setup & configuration
• 4x digital zoom for close-up viewing
2

TP-Link NC220 Specifications

General

Type	IP security camera
PTZ control	-
Antenna type	Internal
Certification	CE, FCC
Placement supported	Indoor
Connectivity technology	Wired & Wireless
Form factor	Cube
Mounting type	Desk/Wall
Product color	White
LED indicators	Yes
Full HD	No
Maximum resolution	640 x 480 pixels
Video formats supported	H.264
Supported graphics resolutions	320 x 240
Minimum illumination	0.5 lx
Sensor type	CMOS
Optical sensor size	1/4 \
Effective sensor resolution	0.3 pixels
Digital zoom	4 x
Optical zoom	- x
Focal length range	2.8 - 3.85 mm
Security algorithms	WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Wi-Fi data rate (max)	300 Mbit/s
Supported network protocols	Bonjour, TCP/IP, DHCP, PPPoE, ARP, ICMP, FTP, SMTP, Samba, NFS, DNS, NTP, UPnP, HTTP, HTTPS, TCP, UDP
Interface	RJ-45
Ethernet LAN (RJ-45) ports	1
Audio system	1-way
Audio formats supported	AAC
AC input voltage	9 V
Power consumption (typical)	5.4 W
Sustainability certificates	RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Mac operating systems supported	Mac OS X 10.7 Lion

Weight and Dimensions

Depth	24 mm
Width	61 mm
Height	96 mm
