7
Tips:
• If you want to power your EAPs using a PoE switch, refer to the following topology.
In
ternet
Clients
Router (DHCP Server)
WANLAN
EAP
EAP
PoE Switch
• The router is the gateway of the network, and devices in the LAN surf the internet via the router.
At the same time, the router acts as a DHCP server to assign dynamic IP addresses to the EAPs
and clients.
