Monitor the Radio Settings
You can monitor the radio settings of the EAP. The following figure posted in the
introduction takes 2.4GHz as an example.
The following table introduces the displayed information of the EAP.
Wireless Radio Displays whether wireless function is enabled on the radio band.
Channel Frequency Displays the channel and frequency which are currently used by the
EAP.
Channel Width Displays the channel width which is currently used by the EAP.
IEEE802.11 Mode Displays the IEEE802.11 protocol currently used by the EAP.
Max TX Rate Displays the maximum physical rate of the EAP.
Tx Power Displays the transmit power of the EAP.
Monitor Radio Traffic
You can monitor the radio traffic of the EAP. The following figure posted in the introduction
takes 2.4GHz of a dual-band device as an example.
The following traffic information of the radio is displayed:
Rx Packets Displays the total number of the received packets on the current band
since the EAP starts up.
