TP-Link RE210 User Manual

RE210
AC750 Wi-Fi Range Extender User Guide
2
Chapter 1 Introduction
1.1 Product Overview
The RE210 AC750 Wi-Fi Range Extender is dedicated to Small Office/Home Office (SOHO)
wireless network solutions. It will enlarge your existing wireless network and mobility within your
wireless network while also allowing you to connect a wired device to a wireless environment.
Increased mobility and the absence of cabling will be beneficial for your network.
With using IEEE 802.11ac wireless technology, this device can transmit wireless data at the rate
of up to 300Mbps (2.4GHz) + 433Mbps (5GHz). With multiple protection measures, including
wireless LAN 64/128/152-bit WEP encryption, Wi-Fi protected Access (WPA2-PSK, WPA-PSK),
the RE210 AC750 Wi-Fi Range Extender delivers complete data privacy. It is also compatible with
all IEEE 802.11n, IEEE 802.11a, IEEE 802.11b and IEEE 802.11g products.
It supports an easy wireless connection to the root Router/AP (equipped with WPS/QSS button) by
pressing the RE button on the side panel. It also supports an easy, web-based setup for
installation and management. Even though you may not be familiar with the Range Extender, you
can easily configure it with the help of this Guide. Before installing the Range Extender, please
look through this Guide to get the full information of the RE210 AC750 Wi-Fi Range Extender.
1.2 Main Features
 Complies with IEEE 802.11ac
 Provides multiple encryption security Types including: 64/128/152-bit WEP and
WPA-PSK/WPA2-PSK
 Supports Built-in DHCP server
 Supports Firmware Upgrade
 Supports Web-based Management
1.3 Appearance
Figure 1-1

TP-Link RE210 Specifications

General

Wi-Fi	Yes
WLAN data transfer rates supported	1, 6, 11, 54, 108, 270, 300 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	1
Data network	Not supported
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Operating frequency	2400 & 5000 MHz
Security algorithms	128-bit WEP, 64-bit WEP, WPA-PSK, WPA2-PSK
Networking standards	IEEE 802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Wi-Fi data rate (max)	750 Mbit/s
Product color	White
Power consumption	6000 mA
Power consumption (typical)	6.5 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Type	Network repeater
Maximum transfer distance	- m
Certification	CE, FCC
Sustainability certificates	RoHS
Antenna type	Internal
Antennas quantity	2
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	89 mm
Width	100.5 mm
Height	155.5 mm
