TP-Link RE330 User Manual

8
Chapter 2 Set Up Internet Connection
Laptop
Smartphone
Tablet
Smart TV
Game Console
Desktop
7. Method 2: Via a Web Browser
1. Connect your computer to the extender wirelessly as follows:
• For Windows Users
1 ) Unplug the Ethernet cable from your computer (if any).
2 ) Click the Wi-Fi icon on the taskbar and connect to the extender’s wireless network:
TP-Link_Extender.
C
onnections are available
Wireless Network
C
onnection
TP-Link_Extender
Connect automatically
Connect
√
• For Mac OS X Users
1 ) Unplug the Ethernet cable from your computer (if any).
2 ) Click the Wi-Fi icon in the top right corner of the screen, and connect to the
extender’s network: TP-Link_Extender.
Wi-Fi: On
Tu rn Wi-Fi O
Join Other Network...
Create Network...
Open Network Preferences...
TP-Link_Extender
2. Follow the instructions of the Quick Setup Wizard to connect the extender to your
host router.
1 ) Launch a web browser, enter http://tplinkrepeater.net or http://192.168.0.254 in
the address bar, and then create a password to log in.
Note:
If the login window does not appear, please refer to FAQ.
Downloaded from ManualsNet.com search engine

TP-Link RE330 Specifications

General

Type	Network repeater
Ethernet LAN data rates	10, 100 Mbit/s
Maximum transfer distance	- m
Antenna type	Internal
Antennas quantity	2
Wi-Fi	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Cabling technology	10/100Base-T(X)
Security algorithms	64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN (RJ-45) ports	1
Product color	White
Quantity per pack	1 pc(s)
Power consumption (typical)	9.5 W
Package type	Box
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	35 mm
Width	69.5 mm
Height	124.1 mm
