TP-Link TL-SG2452 User Manual

Configuring Layer 2 Multicast IGMP Snooping Configuration
User Guide 218
Choose the menu
L2 FEATURES > Multicast > IGMP Snooping > Static Group Config
and
click to load the following page.
Figure 2-4 Configure Hosts to Statically Join a Group
Follow these steps to configure hosts to statically join a group:
1) Specify the multicast IP address, VLAN ID. Select the ports to be the static member
ports of the multicast group.
Multicast IP Specify the address of the multicast group that the hosts need to join.
VLAN ID Specify the VLAN that the hosts are in.
Member Ports Select the ports that the hosts are connected to. These ports will become the
static member ports of the multicast group and will never age.
2) Click Create.
2.2 Using the CLI
2.2.1 Configuring IGMP Snooping Globally
Follow these steps to configure IGMP Snooping globally:
Step 1 configure
Enter global configuration mode.
Step 2 ip igmp snooping
Enable IGMP Snooping Globally.

TP-Link TL-SG2452 Specifications

General

Switching Capacity	104 Gbps
Forwarding Rate	77.38 Mpps
MAC Address Table	16 K
Weight	3.5 kg
Fan Quantity	2
Mounting	Rack mountable
Jumbo Frame	9 KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 90% non-condensing
Ports	48 x 10/100/1000Mbps RJ45 ports, 4 x 1G SFP slots
Dimensions (W x D x H)	440 x 220 x 44 mm
Power Supply	100-240V AC, 50/60Hz
Standards and Protocols	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p
L2 Features	VLAN, Port Mirroring, Link Aggregation
VLAN	802.1Q VLAN
Security	DHCP Snooping
Management	SNMP v1/v2c/v3
Quality of Service	802.1p QoS
