108
450Mbps High Power Wireless N Router
Chapter 4. Range Extender Mode
4.1 Login and switch the working mode
Enter http://tplinkwifi.net in the address bar of a web browser. Use admin for both username
and password, and then click Login.
Figure 4-1 Login
After your successful login, you can either click the Mode button on the top-right corner of the
Web management page or press the RE button on the top panel of the router to switch the
working mode of the router to Range Extender.
4.2 Quick Setup
Refer to Range Extender->Option one configure
4.3 Setting
Click “Setting”, then you will see the main menus on the left of the Web Management Page. On
the right, there are the corresponding explanations and instructions.
The detailed explanations for each Web page’s key function are listed below.
4.3.1 Status
Go to “Setting→Status”, you can see the current status information about the router.
