450Mbps High Power Wireless N Router
Ingress bandwidth - This field displays the max and mix download bandwidth through the
Internet port, the default is 0.
Enable - This displays the status of the rule.
Modify - Click Modify to edit the rule. Click Delete to delete the rule.
To add/modify a Bandwidth Control rule, follow the steps below.
1. Click Add New… shown in Figure 3-66, you will see a new screen shown in Figure 3-67.
2. Enter the information like the screen shown below.
Figure 3-67 Bandwidth Control Rule Settings
3. Click the Save button.
3.4.13 IP & MAC Binding
There are two submenus under the IP &MAC Binding menu: Binding Settings and ARP List.
Click any of them, and you will be able to scan or configure the corresponding function. The
detailed explanations for each submenu are provided below.
3.4.13.1. Binding Settings
Go to “Advanced→Bandwidth Control→Binding Setting”, you can configure the IP & MAC
binding rules in this page.
