TP-Link TL-WR941HP

175
TL-WR941HP
450Mbps High Power Wireless N Router
Appendix C: Specifications
General
Standards
IEEE 802.11g、IEEE 802.11b、IEEE 802.11n、IEEE 802.3、IEEE
802.3u、IEEE 802.3x、IEEE 802.1X、IEEE 802.11e、IEEE 802.11i
Protocols
TCP/IP, PPPoE, DHCP, ICMP, NAT, SNTP
Ports
One 10/100M Auto-Negotiation WAN RJ45 port, Four 10/100M
Auto-Negotiation LAN RJ45 ports supporting Auto MDI/MDIX
Cabling Type
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
LEDs
PWR, SYS, WLAN, LAN (1-4), WAN, WPS
Safety & Emissions
FCC
Wireless
Frequency Band
2.4~2.4835GHz
Radio Data Rate
11n：up to 300Mbps（Automatic）
11g：54/48/36/24/18/12/9/6M（Automatic）
11b：11/5.5/2/1M（Automatic）
Frequency Expansion
DSSS (Direct Sequence Spread Spectrum)
Modulation
BPSK, QPSK, CCK, OFDM, 16-QAM, 64-QAM
Security
WEP/WPA/WPA2/WPA2-PSK/WPA-PSK
Sensitivity @PER
270M: -68dBm@10% PER
130M: -68dBm@10% PER
108M: -68dBm@10% PER
54M: -68dBm@10% PER
11M: -85dBm@8% PER
6M: -88dBm@10% PER
1M: -90dBm@8% PER
Antenna Gain
7.5dBi *3
Environmental and Physical
Temperature
Operating : 0℃~40℃ (32℉~104℉)
Storage: -40℃~70℃(-40℉~158℉)
Humidity
Operating: 10% - 90% RH, Non-condensing
Storage: 5% - 90% RH, Non-condensing
