450Mbps High Power Wireless N Router
1. Turn on the router.
2. Connect the router to your wired host router’s Ethernet port via an Ethernet cable as shown
above.
3. Connect a computer to the router via an Ethernet cable or wirelessly by using the SSID
(network name) and password printed on the bottom label of the router.
2.4.4.2. Login and Quick Setup
1. Enter http://tplinkwifi.net in the address bar of a web browser. Use admin for both
username and password, and then click Login.
Figure 2-7 Login the Router
Figure 2-8 Login Windows
Note:
If the above screen does not pop-up, it means that your Web-browser has been set to a proxy.
Go to Tools menu > Internet Options > Connections > LAN Settings, in the screen that appears,
cancel the Using Proxy checkbox, and click OK to finish it.
2. After successfully login, Click Mode button on the top-right corner of the Web Management
Page and choose Access Point and then click Save. The router will reboot automatically.
Note:
If you want to change the default SSID(network name) and the password, please follow
Quick Setup to complete the configuration.
