The panel of Base Station
Panel Layout
RESET
Shielded Ethernet
Port LAN1
Shielded Ethernet
Port LAN0(POE IN)
Grounding Terminal
2
AP/AP Router mode: All four LEDs remain solid.
Client/Bridge/Repeater/AP Client Router mode:
The more lit LEDs indicate the better wireless signal strength.
On: The port is connected but not active.
Flashing: The port is transmitting data.
On: The Base Station is powered on.
LED Explanation
LAN1
LAN0(POE IN)
GND
Chain1
Chain0
