4
Affix the waterproof rubber insert to
the underside of the device for
waterproofing and replace the cover
until it firmly locks into place.
Use an adequate Ethernet cable to
connect the LAN0 (POE IN) port. The
length of cable is up to 60m for
steady power supply. Shielded CAT5e
(or above) cable with an integrated
ground wire is recommended.
2
Connect the RF Cables to the Base
Station.
4
3
Firmly grasp the rear of the interface
cover and pull it downward.
1
Connect Cables
To Next Page
