TPS WP-80 - Relative mV Calibration

Page 11
3.1.3 Relative mV Mode
Displays Relative mV and Temperature readings simultaneously.
Press to alternatively show absolute mV or the date and time. For
example…
1000mVR 25.0
660mV F4:Zeros
ÖÖ
1000mVR 25.0
31/12 12:00:00
If the temperature probe is unplugged, no temperature value is
displayed…
1000mVR
660mV F4:Zeros
ÖÖ
1000mVR
31/12 12:00:00
Notes
1. Temperature compensation does not apply in mV mode.
2. The decimal point is replaced by a ∗∗ if a pH or Temperature
calibration has failed (sections 4.1, and 7.1) if the unit is initialised
(section 15), or if the unit has lost its factory calibration (section 16.1).
