Tracker Off-Road 800SX - Page 134

132
P0643 Sensor Reference Voltage #1 Circuit High 5-volt sensor power circuit #1 has been shorted to battery power. Correct condition*
P0651 Sensor Reference Voltage #2 Circuit
Low/Open
5-volt sensor power circuit #2 has been shorted to chassis ground. Correct condition*
P0653 Sensor Reference Voltage #2 Circuit High 5-volt sensor power circuit #1 has been shorted to battery power. Correct condition*
P0685 EFI/Main Relay Circuit Open The Main/EFI relay has been removed or its circuit is open. Correct condition*
P0686 EFI/Main Relay Circuit Low/SG The Main/EFI relay or its circuit is shorted to chassis ground. Correct condition*
P0687 EFI/Main Relay Circuit High/SP The Main/EFI relay or its circuit is shorted to battery power. Correct condition*
P0691 Fan-Primary Relay Control Circuit
Low/SG
The primary fan relay or its interconnect harness is shorted to
chassis ground.
Correct condition*
P0692 Fan-Primary Relay Control Circuit
High/SP
The primary fan relay or its interconnect harness is shorted to
battery power.
Correct condition*
P0693 Fan-Secondary Relay Control Circuit
Low/SG
The secondary fan relay or its interconnect harness are shorted to
ground.
Correct condition*
P0694 Fan-Secondary Relay Control Circuit
High/SP
The secondary fan relay or its interconnect harness are shorted to
battery power.
Correct condition*
P1120 Throttle Position Sensor Lower Position
The electronic throttle valve was unable to cycle through its entire
self check range.
Correct condition*
P1121 Throttle Position Sensor Lower Adaption
The electronic throttle valve was unable to cycle through its entire
self check range.
Correct condition*
P1122 Throttle Position Sensor Lower Return The electronic throttle valve was unable to cycle through its entire
self check range.
Correct condition*
P1123 Throttle Position Sensor Adaption
Condition
The electronic throttle valve was unable to cycle through its entire
self check range.
Correct condition*
P1124 Throttle Position Sensor Limp Home
Adaption
The electronic throttle valve was unable to cycle through its entire
self check range.
Correct condition*
P1125 Throttle Position Sensor Upper Position
The electronic throttle valve was unable to cycle through its entire
self check range.
Correct condition*
P1126 Throttle Position Sensor Upper Return
The electronic throttle valve was unable to cycle through its entire
self check range.
Correct condition*
P2100 Throttle Actuator Control Motor Circuit
Open
The electronic throttle control actuator or its interconnect harness is
open.
Correct condition*
P2102 Throttle Actuator #1 Control Motor Circuit
Low/SG
The electronic throttle control actuator or its interconnect harness is
shorted to chassis ground.
Correct condition*
P2103 Throttle Actuator #1 Control Motor Circuit
High/SP
The electronic throttle control actuator or its interconnect harness is
shorted to battery power.
Correct condition*
P2106 Electronic Throttle Control Output Is Out
Of Range
The ECM detected an internal condition. Correct condition*
P2107 Electronic Throttle Control Driver
Over-Temperature
The ECM detected an internal condition. Correct condition*
P210C Throttle Actuator #2 Control Motor Circuit
Low/SG
The electronic throttle control actuator or its interconnect harness is
shorted to chassis ground.
Correct condition*
P210D Throttle Actuator #2 Control Motor Circuit
High/SP
The electronic throttle control actuator or its interconnect harness is
shorted to battery power.
Correct condition*
P2118 Throttle Actuator Control Motor Range
Error
The electronic throttle control actuator wires or its interconnect
harness are shorted together.
Correct condition*
P2119 Throttle Control Actuator Control
Performance Error
Either the positive or the negative wire of the electronic throttle
control actuator or its interconnect harness is open.
Correct condition*
P2122 Pedal Position Sensor #1 Circuit
Low/Open/SG
The pedal position sensor or its interconnect harness is shorted to
chassis ground or open.
Correct condition*
P2123 Pedal Position Sensor #1 Circuit High/SP The pedal position sensor or its interconnect harness is shorted to
battery power.
Correct condition*
P2127 Pedal Position Sensor #2 Circuit Low/
Open/SG
The pedal position sensor or its interconnect harness is shorted to
chassis ground or open.
Correct condition*
P2128 Pedal Position Sensor #2 Circuit High/SP
The pedal position sensor or its interconnect harness is shorted to
battery power.
Correct condition*
P2135 Throttle Position Sensor Plausibility Error One of the throttle position sensor circuits is shorted to either
battery power, ground, is open, or a faulty sensor.
Correct condition*
P2138 Pedal Position Sensor Plausibility Error One of the throttle position sensor circuits is shorted to either
battery power, ground, is open, or a faulty sensor.
Correct condition*
P2299 Brake Pedal Position/Accelerator Pedal
Position Incompatible
The brake light pressure switch is active while the accelerator pedal
is being depressed.
Correct condition*
P2300 Ignition Coil #1 Primary Circuit Low/SG/
Open
Ignition coil #1 primary circuit or its interconnect harness is open or
shorted to chassis ground.
Correct condition**
P2301 Ignition Coil #1 Primary Circuit High
Ignition coil #1 primary circuit or its interconnect harness is shorted
to battery power.
Correct condition**
P2303 Ignition Coil #2 Primary Circuit Low/Open Ignition coil #2 primary circuit or its interconnect harness is open or
shorted to chassis ground.
Correct condition**
P2304 Ignition Coil #2 Primary Circuit High
Ignition coil #2 primary circuit or its interconnect harness is shorted
to battery power.
Correct condition**
P2306 Ignition Coil #3 Primary Circuit Low/Open
Ignition coil #3 primary circuit or its interconnect harness is open or
shorted to chassis ground.
Correct condition**
P2307 Ignition Coil #3 Primary Circuit High Ignition coil #3 primary circuit or its interconnect harness is shorted
to battery power.
Correct condition**
P2610 ECU Warm Reset
System voltage may have been temporarily too low to power the
ECU.
Correct condition*
Display Fault Description Possible Cause Fault Recovery Method
