161
8. Install the snap ring.
G. Reverse Shaft
1. Inspect the bearings for free and smooth turning. If
either bearing does not turn freely, it must be
replaced.
TA048
TA055
2. Inspect the gear teeth for nicks, cracks, chips, or
signs of wear. If any are present, the gear must be
replaced.
TA049
TA050
TA051
3. Inspect the shaft gear teeth for nicks, cracks, chips,
or signs of wear. If any are present, the shaft must be
replaced.
TA052
TA053
4. Inspect the dogs for nicks, cracks, chips, or signs of
wear. If any are present, the dog must be replaced.
To Next Page
