15
3. Remove the taillight/brake light assembly and dis-
connect it from the harness by pushing on the con-
nector lock.
MOD110
MOD112A
4. Install the new assembly, making sure to connect the
harness.
MOD112
5. Install screw (A) first; then flex the cargo box fender
away from the cargo box to access and install screw
(B).
MOD117A
MOD113
6. Position the outer cargo box side panel behind the
two tabs on the cargo box fender; then fit all tabs into
their adjoining slots in the side panel.
MOD116A
7. With a suitable pry bar, lift up on the inner cargo box
floor near the rear corner.
MOD110A
